photo-electric sensor - XUY - fork - 2X40mm - 12..24VDC - cable 2m

Ülevaaded: 0

Tootekood: XUYF953002S

Quick Overview

Saadavus: Tellimisel

165,92 € (ilma KM-ta)

Details

Main
range of product
OsiSense XU
series name
Application
electronic sensor type
Photo-electric sensor
sensor name
XUY
sensor design
Fork
detection system
Thru beam
emission
Infrared, continuous
passage width
2 mm
passage depth
40 mm
material
Metal
supply circuit type
DC
wiring technique
4-wire
discrete output type
PNP/NPN
electrical connection
Cable
cable length
2 m
product specific application
Control of tools travel
Detection of sheets overlapping
Lateral shift control of a belt
Detection of marks on a translucent film
Lift cage position control
Detection on a labelling machine
[Sn] nominal sensing distance
2 mm
Complementary
enclosure material
Painted aluminium strong housing
type of output signal
Discrete
output type
Solid state
[Us] rated supply voltage
12...24 V DC reverse polarity protection
supply voltage limits
10…30 V DC
switching capacity in mA
100 mA overload and short-circuit protection)
switching frequency
10 kHz
maximum voltage drop
<1 V 10 mA closed state)
<2 V 100 mA closed state)
current consumption
40 mA no-load
time response
30 µs
maximum delay recovery
30 µs
depth
12 mm
length
60 mm
width
40 mm
Environment
product certifications
CE
CULus
ambient air temperature for operation
-20…60 °C
ambient air temperature for storage
-20…80 °C
immunity to ambient light
3000 lux incandescent bulb
3000 lux natural light
IP degree of protection
IP65 IEC 60529
Offer Sustainability
REACh-määrus
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Contractual warranty
Garantii
18 months
