PratiKa industrial plug - 16 A - 3P + N + E - 200...250 V AC - IP67

Ülevaaded: 0

Tootekood: 83856

Quick Overview

Saadavus: Tellimisel

7,02 € (ilma KM-ta)

Details

Main
range
PratiKa
product or component type
Plug
device short name
PratiKa plug
plug, socket category
Low voltage
poles description
3P + N + E
network type
AC
outlet standard
Industrial
Complementary
mounting mode
Panel-mounted
plug, socket, control station shape
90° angled
[In] rated current
16 A
[Ue] rated operational voltage
200...250 V
network frequency
50/60 Hz
ground lug clockwise position
9 h
plug, socket material
Self-extinguishing engineering polymer
contacts material
Pins: nickel plated brass
connections - terminals
Captive screws
cable cross section
1…4 mm²
net weight
0.256 kg
base dimension
90 x 100 mm
height
148 mm
width
90 mm
depth
107 mm
colour
Grey (RAL 7035)
voltage colour
Blue
Environment
standards
EN 60309-2
EN 60309-1
IP degree of protection
IP67 conforming to IEC 60529
IK degree of protection
IK08 conforming to EN 62262
fire resistance
850 °C conforming to IEC 60695-2-1
relative humidity
50 % at 40 °C
70 % at 30 °C
90 % at 20 °C
operating altitude
2000 m
ambient air temperature for operation
35 °C ( 86400 s )
-25…40 °C
Offer Sustainability
Sustainable offer status
Green Premium product
EU RoHS Directive
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
China RoHS declaration
Product out of China RoHS scope. Substance declaration for your information
Environmental Disclosure
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty
Warranty
18 months
