PratiKa socket - fast - straight - 16A - 3P + E - 100...130 V AC - panel

Ülevaaded: 0

Tootekood: PKY16G714

Quick Overview

Saadavus: Tellimisel

10,99 € (ilma KM-ta)

Details

Main
range
PratiKa
product or component type
Socket
device short name
PratiKa socket
plug, socket category
Low voltage
poles description
3P + E
network type
AC
outlet standard
Industrial
Complementary
mounting mode
Panel-mounted
plug, socket, control station shape
Straight
[In] rated current
16 A
[Ue] rated operational voltage
100...130 V
network frequency
50/60 Hz
ground lug clockwise position
4 h
plug, socket material
Housing: self-extinguishing engineering polymer
contacts material
Sleeves: brass
connections - terminals
Fast connection
cable cross section
1…2.5 mm²
net weight
0.19 kg
base dimension
65 x 85 mm
height
85 mm
width
81 mm
depth
94 mm
colour
Grey (RAL 7035)
voltage colour
Yellow
Environment
standards
IEC 60309-2
IEC 60309-1
IP degree of protection
IP67 conforming to IEC 60529
IK degree of protection
IK08 conforming to EN 62262
fire resistance
850 °C conforming to IEC 60695-2-1
relative humidity
50 % at 40 °C
70 % at 30 °C
90 % at 20 °C
ambient air temperature for operation
35 °C ( 86400 s )
Contractual warranty
Warranty
18 months
