pressure sensor XMLK - 0..6bar - G 1/4A - 4..20mA - M12 - set of 1

Product was successfully added to your shopping cart.

pressure sensor XMLK - 0..6bar - G 1/4A - 4..20mA - M12 - set of 1

Tootekood: XMLK006B2D21

Quick Overview

Saadavus: Tellimisel

119,39 € (ilma KM-ta)

Qty:

Details

Main
range of product	OsiSense XM
product or component type	Electronic pressure sensors
pressure sensor type	Pressure transmitter
pressure sensor name	XMLK
electrical circuit type	Control circuit
pressure sensor size	6 bar
local display	Without
controlled fluid	Air (0…80 °C) Fresh water (0…80 °C)
fluid connection type	G 1/4A (male) conforming to DIN 3852-E
electrical connection	1 male connector M12 4 pins
[Us] rated supply voltage	24 V DC SELV (voltage limits: 8…33 V)
current consumption	< 20 mA
type of output signal	Analogue
analogue output function	4...20 mA, 2-wire
quantity per set	Set of 1
type of packing	Individual

Complementary
pressure setting range	0…6 bar
maximum permissible accidental pressure	12 bar
destruction pressure	18 bar
materials in contact with fluid	Ceramic Nitrile (NBR) Stainless steel type AISI 303
operating position	Any position
protection type	Reverse polarity Load short-circuit
electromagnetic compatibility	Electrostatic discharge immunity test conforming to EN/IEC 61000-4-2 8 kV air, 6 kV contact Susceptibility to electromagnetic fields conforming to EN/IEC 61000-4-3 10 V/m 80...1000 MHz Electrical fast transient/burst immunity test conforming to EN/IEC 61000-4-4 2 kV 1.2/50 µs shock waves immunity test conforming to EN/IEC 61000-4-5 500 V 12 Ohm, 1 kV 42 Ohm Radiated RF fields conforming to EN/IEC 61000-4-6 10 V 0.15...80 MHz Immunity to magnetic fields conforming to EN/IEC 61000-4-8 30 A/m 50 Hz
[Uimp] rated impulse withstand voltage	0.5 kV
response time on output	< 5 ms
measurement accuracy	+/- 1 % of the measuring range
Resolution	0.1 % of the measuring range
drift of the sensitivity	+/- 0.04 % of measuring range/°K
drift of the zero point	+/- 0.03 % of measuring range/°K
Long term stability	+/- 1 % of the measuring range
mechanical durability	10000000 cycles
net weight	0.11 kg
diameter	36 mm
length	67.5 mm
scale type	Fixed differential

Environment
standards	EN/IEC 61326-2-3 CE
product certifications	EAC UL 508 RCM CSA C22.2 No 14
protective treatment	TC
ambient air temperature for operation	0…80 °C
ambient air temperature for storage	-25…80 °C
vibration resistance	20 gn (f = 9…2000 Hz) conforming to EN/IEC 60068-2-6
shock resistance	25 gn for 11 ms conforming to EN/IEC 60068-2-27
IP degree of protection	IP65 conforming to EN/IEC 60529
NEMA degree of protection	NEMA 4

Offer Sustainability
REACh free of SVHC	Yes
EU RoHS Directive	Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration
Mercury free	Yes
RoHS exemption information	Yes

Contractual warranty
Warranty	18 months
