rectified and filtered power supply - 1 or 2-phase - 400 V AC - 24 V - 6 A

Ülevaaded: 0

Tootekood: ABL8FEQ24060

Quick Overview

Saadavus: Tellimisel

252,42 € (ilma KM-ta)

Details

Main
range of product
Phaseo Rectified
product or component type
Power supply
power supply type
Rectified and filtered
rated power in W
144 W
Nominal input voltage
230 V AC single phase N-L1
400 V AC phase to phase L1-L2
output voltage
24 V DC
power supply output current
6 A
anti-harmonic filter
Low frequency harmonic currents
product certifications
KC
UL 508
EAC
CULus
Complementary
network frequency limits
47…63 Hz
input voltage limits
207...253 V
360...440 V
Power Factor
0,781 230 V
0,86 400 V
efficiency
75 %
power dissipation in W
36 W
output coupling
Series
Parallel
output protection type
Against overload and short-circuits internal fuse, 6,3 A, 5 x 20 mm, T
Against overvoltage 2 J peak limiter
Hold-up time
14 ms
status LED
Output voltage 1 LED green)
Input voltage 1 LED orange)
residual ripple
<= 1200 MV
connections - terminals
Input connection screw type terminals 5 x 2.5...5 x 4 mm² AWG 14...AWG 11
Input ground connection screw type terminals 1 x 2.5...1 x 4 mm² AWG 14...AWG 11
Output connection screw type terminals 4 x 2.5...4 x 4 mm² AWG 14...AWG 11
depth
153 mm
height
153 mm
width
123 mm
net weight
4,94 kg
compatibility code
ABL8F
Environment
IP degree of protection
IP20 EN/IEC 60529
ambient air temperature for operation
-20…60 °C
ambient air temperature for storage
-40…80 °C
relative humidity
0…95 % without condensation or dripping water
operating altitude
3000 m
Safety class
Class I VDE 0106-1
dielectric strength
2000 V between input and ground
4600 V between input and output
500 V between output and ground
Other environmental characteristic
EMC IEC 62041
Safety EN/IEC 61558-2-6
Safety UL 508
Safety UL 60950-1
EMC EN/IEC 61000-3-2
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Keskkonnaalane avaldus
Ringlusprofiil
Contractual warranty
Garantii
18 months
