red light block with body/fixing collar with BA9s LED bulb 400V

Ülevaaded: 0

Tootekood: ZB5AV5D4

Quick Overview

Saadavus: Tellimisel

16,01 € (ilma KM-ta)

Details

Main
range of product
Harmony XB5
product or component type
Complete body/light block assembly
device short name
ZB5
fixing collar material
Plastic
sale per indivisible quantity
1
connections - terminals
Screw clamp terminals, <= 2 x 1.5 mm² with cable end EN 60947-1
Screw clamp terminals, >= 1 x 0.22 mm² without cable end EN 60947-1
light source
LED
bulb base
BA 9s
light block supply
Via integral transformer 1,2 VA 6 V
light source colour
Red
Complementary
CAD overall width
30 mm
CAD overall height
42 mm
CAD overall depth
55 mm
terminals description ISO n°1
(X1-X2)PL
net weight
0,102 kg
tightening torque
0,8…1,2 N.m EN 60947-1
shape of screw head
Cross Philips no 1
Cross pozidriv No 1
Slotted flat Ø 4 mm
Slotted flat Ø 5.5 mm
[Ui] rated insulation voltage
600 V 3)EN 60947-1
[Uimp] rated impulse withstand voltage
6 kV EN 60947-1
signalling type
Steady
[Us] rated supply voltage
400 V AC 50/60 Hz
mounting of block
Front mounting
electrical composition code
P4
M9
Environment
protective treatment
TH
ambient air temperature for storage
-40…70 °C
ambient air temperature for operation
-40…70 °C
electrical shock protection class
Class II IEC 60536
standards
EN/IEC 60947-5-1
EN/IEC 60947-1
JIS C8201-5-1
CSA C22.2 No 14
EN/IEC 60947-5-4
UL 508
JIS C8201-1
product certifications
BV
GL
UL listed
CSA
RINA
LROS (Lloyds register of shipping)
DNV
vibration resistance
5 gn 2…500 Hz)IEC 60068-2-6
shock resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27
50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
Ilma SVHC REACh-ta
Jah
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Keskkonnaalane avaldus
Ringlusprofiil
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
