red Ø30 Emergency stop pushbutton Ø16 trigger latching turn release 1NO+2NC

Ülevaaded: 0

Tootekood: XB6AS8349B

Quick Overview

Saadavus: Tellimisel

18,77 € (ilma KM-ta)

Details

Main
range of product
Harmony XB6
product or component type
Complete emergency stop push-button
device short name
XB6
bezel material
Plastic
mounting diameter
16 mm
sale per indivisible quantity
1
shape of signaling unit head
Round
type of operator
trigger action and mechanical latching
reset
Turn to release
operator profile
Red mushroom Ø 30 mm, unmarked
contacts type and composition
1 NO + 2 NC
contact operation
Slow-break
connections - terminals
Faston connectors 2.8 x 0.5 mm
Complementary
height
30 mm
width
30 mm
depth
77 mm
terminals description ISO n°1
(31-32)NC
(13-14)NO
(21-22)NC
net weight
0,041 kg
operating position
Any position
type of keylock
Ronis 200
contacts usage
Standard
positive opening
With EN/IEC 60947-5-1 appendix K
operating travel
1 mm NC changing electrical state)
2 mm NO changing electrical state)
3,5 mm total travel)
operating force
3,5 N NO changing electrical state
4,5 N NC changing electrical state
mechanical durability
100000 cycles
contacts material
Silver alloy (Ag/Ni)
short-circuit protection
6 A cartridge fuse gG
[Ui] rated insulation voltage
250 V 3)EN/IEC 60947-1
[Uimp] rated impulse withstand voltage
4 kV EN/IEC 60947-1
[Ie] rated operational current
3 A 120 V, AC-15, B300 EN/IEC 60947-5-1
1,5 A 240 V, AC-15, B300 EN/IEC 60947-5-1
0,1 A 250 V, DC-13, R300 EN/IEC 60947-5-1
0,22 A 125 V, DC-13, R300 EN/IEC 60947-5-1
electrical durability
1000000 cycles, AC-15 230 V 3600 cyc/h 0,5 EN/IEC 60947-5-1 appendix C
1000000 cycles, DC-13 230 V 3600 cyc/h 0,5 EN/IEC 60947-5-1 appendix C
electrical reliability
Λ < 10exp(-8) 5 V, 1 mA with confidence level of 90 % IEC 60947-5-4
Environment
protective treatment
TC
ambient air temperature for storage
-40…70 °C
ambient air temperature for operation
-25…70 °C
electrical shock protection class
Class II IEC 61140
IP degree of protection
IP65 IEC 60529
NEMA degree of protection
NEMA 13 UL 50
NEMA 4 UL 50
NEMA 4X UL 50
NEMA 13 CSA C22.2 No 94
NEMA 4X CSA C22.2 No 94
NEMA 4 CSA C22.2 No 94
standards
UL 508
JIS C 852
CSA C22.2 No 14
EN/IEC 60947-5-1
EN/IEC 60204-1
EN/ISO 13850
EN/IEC 60947-5-5
JIS C8201-5-1
EN/IEC 60947-1
JIS C8201-1
product certifications
CSA
CCC
GOST
UL
vibration resistance
+/- 3 mm 2…500 Hz)IEC 60068-2-6
5 gn 2…500 Hz)IEC 60068-2-6
shock resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27
50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
Ilma SVHC REACh-ta
Jah
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Mürgiste raskemetallideta
Jah
Elavhõbedavaba
Jah
RoHS eranditeave
Hiina EoHS regulatsioon
Keskkonnaalane avaldus
Ringlusprofiil
WEEE
Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.
Contractual warranty
Garantii
18 months
