Details
Müüdavad tooted
| product or component type | Resistance braking unit ATV61Resistance braking unit ATV71Resistance braking unit ATV930 | |
|---|---|---|
| range compatibility | Altivar 61QAltivar 71QAltivar 71Altivar 61Altivar Process ATV900 | |
| maximum braking power | 420 kW | |
| product compatibility | ATV61HC25N4ATV61HC31N4ATV61QC20N4ATV61QC25N4ATV61QC31N4ATV71HC20N4ATV71HC25N4ATV71HC28N4ATV71QC16N4ATV71QC20N4ATV71QC25N4Variable speed drive ATV930 without braking chopper 250 kW 380...480 VVariable speed drive ATV930 without braking chopper 315 kW 380...480 V | |
| thermal losses | 550 W | |
| activation threshold | 785 V DC +/- 1 % | |
| permanent braking power | 200 kW 400 V at constant power and at engage threshold) | |
| protection type | Integrated thermal protection thermal probe | |
| minimum resistor value to associate | 1.05 Ohm |
| electrical connection | Cable between drive and braking unitCable 2 x 95 mm² between braking unit and braking resistors | |
|---|---|---|
| maximum DC bus voltage | 850 V | |
| load factor | 0,05 420 kW at constant power and at engage threshold0,15 320 kW at constant power and at engage threshold0,5 250 kW at constant power and at engage threshold | |
| maximum cycle time | 240 ms | |
| volume of cooling air | 100 m3/h | |
| operating position | Vertical | |
| net weight | 30 kg |
| ambient air temperature for operation | -10…50 °C | |
|---|---|---|
| ambient air temperature for storage | -25…70 °C | |
| IP degree of protection | IP20 | |
| pollution degree | 2 EN 50178 | |
| environmental characteristic | Biological pollution resistance class 3B1 IEC 60721-3-3Chemical pollution resistance class 3C3 IEC 60721-3-3Dust pollution resistance class 3S3 IEC 60721-3-3Humidity resistant class 3K3 IEC 60721-3-3 | |
| operating altitude | 2000 m | |
| vibration resistance | 0.2 gn |
| ELi RoHS direktiiv | Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse) ELi RoHS deklaratsioon | |
|---|---|---|
| Elavhõbedavaba | Jah | |
| RoHS eranditeave | ||
| Hiina EoHS regulatsioon |
| Garantii | 18 months |
|---|
