security light curtain XU2-S - detection of body - Sn 8m - 12..24 VDC - M12

Ülevaaded: 0

Tootekood: XU2S18PP340D

Quick Overview

Saadavus: Tellimisel

141,65 € (ilma KM-ta)

Details

Main
range of product
Preventa Safety detection
product or component type
Safety thru-beam pair photo-electric sensors
device short name
XU2S
output type
1 safety outputs OSSD PNP
[Sn] nominal sensing distance
8 m
Complementary
detection system
Transmitter-receiver system
[Us] rated supply voltage
12...24 V DC 10...30 V reverse polarity protection
current consumption
<= 35 mA no-load
maximum voltage drop
<1,5 V closed)
switching capacity in mA
<= 100 mA overload and short-circuit protection)
switching frequency
500 Hz maximum
electrical connection
1 male connector M12 4 pins
line of sight type
Along case axis
maximum delay response
1 ms
maximum delay recovery
1 ms
tightening torque
24 N.m fixing nut
2 N.m connector
function available
Built-in muting function
Light or dark programmable switching
marking
CE
material
Nickel plated brass case
PMMA (polymethyl methacrylate) lenses
net weight
0,155 kg
Environment
standards
EN/IEC 61496-1
EN/IEC 61496-2
EN/IEC 60825-1
safety level
Can reach PL = c associated with module XPSCM correctly wired EN/ISO 13849-1
Can reach category 2 associated with module XPSCM correctly wired EN/ISO 13849-1
Type 2 IEC 61496-1-2
ambient air temperature for operation
-25…55 °C
safety reliability data
PFH = 5.5E-7 1/h with muting function IEC 61508
PFH = 4.6E-7 1/h IEC 61508
ambient air temperature for storage
-40…70 °C
IP degree of protection
IP67 EN/IEC 60529
shock resistance
30 gn 3 axes : 3 times EN/IEC 60068-2-27
vibration resistance
7 gn 10…55 Hz)EN/IEC 60068-2-6
Offer Sustainability
Jätkusuutliku pakkumise olek
Green Premium toode
REACh-määrus
ELi RoHS direktiiv
Ennetav vastavus (toode ei jää EL-i RoHS seadustega määratud piiridesse)
ELi RoHS deklaratsioon
Elavhõbedavaba
Jah
RoHS eranditeave
Keskkonnaalane avaldus
Ringlusprofiil
Contractual warranty
Garantii
18 months
