switch disconnector, Compact INV320, visible break, 320 A, standard version with black rotary handle, 4 poles

Product was successfully added to your shopping cart.

switch disconnector, Compact INV320, visible break, 320 A, standard version with black rotary handle, 4 poles

Tootekood: 31169

Quick Overview

Saadavus: Tellimisel

232,12 € (ilma KM-ta)

Qty:

Details

Main
range	Compact
product name	Compact INV
product or component type	Switch disconnector
poles description	4P
network type	AC DC
network frequency	50/60 Hz
handle colour	Black
[Ie] rated operational current	AC-21A 320 A AC 50/60 Hz 220/240 V AC-21A 320 A AC 50/60 Hz 380/415 V AC-21A 320 A AC 50/60 Hz 440/480 V AC-21A 320 A AC 50/60 Hz 480 V NEMA AC-21A 320 A AC 50/60 Hz 500/525 V AC-21A 320 A AC 50/60 Hz 660/690 V AC-22A 320 A AC 50/60 Hz 220/240 V AC-22A 320 A AC 50/60 Hz 380/415 V AC-22A 320 A AC 50/60 Hz 440/480 V AC-22A 320 A AC 50/60 Hz 480 V NEMA AC-22A 320 A AC 50/60 Hz 500/525 V AC-22A 320 A AC 50/60 Hz 660/690 V AC-23A 320 A AC 50/60 Hz 220/240 V AC-23A 320 A AC 50/60 Hz 380/415 V AC-23A 320 A AC 50/60 Hz 440/480 V AC-23A 320 A AC 50/60 Hz 480 V NEMA AC-23A 320 A AC 50/60 Hz 500/525 V AC-23A 320 A AC 50/60 Hz 660/690 V DC-21A 320 A DC 125 V 2 poles in series DC-22A 320 A DC 125 V 2 poles in series DC-23A 320 A DC 125 V 2 poles in series DC-21A 320 A DC 250 V 4 poles in series DC-22A 320 A DC 250 V 4 poles in series DC-23A 320 A DC 250 V 4 poles in series
[Ui] rated insulation voltage	750 V AC 50/60 Hz
[Uimp] rated impulse withstand voltage	8 kV
[Ith] conventional free air thermal current	320 A 60 °C
[Icm] rated short-circuit making capacity	330 kA with upstream protection circuit breaker 690 V AC 50/60 Hz 50 kA switch-disconnector alone 690 V AC 50/60 Hz
[Ue] rated operational voltage	690 V AC 50/60 Hz 250 V DC
suitability for isolation	Yes
contact position indicator	Yes
visible break	Yes
pollution degree	3

Complementary
control type	Rotary handle
mounting mode	Fixed
mounting support	Rail Plate
upside connection	Front
downside connection	Front
maximum power	AC-23 160 kW 380/415 V AC 50/60 Hz AC-23 185 kW 440 V AC 50/60 Hz AC-23 185 kW 480 V AC 50/60 Hz NEMA) AC-23 220 kW 500/525 V AC 50/60 Hz AC-23 250 kW 660/690 V AC 50/60 Hz AC-23 90 kW 220/240 V AC 50/60 Hz AC-23 90 kW 230 V AC 50/60 Hz NEMA)
rated duty	Uninterrupted
[Icw] rated short-time withstand current	11,5 kA 3 s IEC 60947-3 20 kA 1 s IEC 60947-3 4 kA 30 s IEC 60947-3 4,9 kA 20 s IEC 60947-3
mechanical durability	10000 cycles
electrical durability	AC-21A 1000 cycles 440 V AC 50/60 Hz AC-21A 1000 cycles 500 V AC 50/60 Hz AC-21A 1000 cycles 690 V AC 50/60 Hz AC-22A 1000 cycles 440 V AC 50/60 Hz AC-22A 1000 cycles 500 V AC 50/60 Hz AC-22A 1000 cycles 690 V AC 50/60 Hz AC-23A 1000 cycles 440 V AC 50/60 Hz AC-23A 1000 cycles 500 V AC 50/60 Hz AC-23A 1000 cycles 690 V AC 50/60 Hz DC-21A 1000 cycles 250 V DC DC-22A 1000 cycles 250 V DC DC-23A 1000 cycles 250 V DC
connection pitch	45 mm
height	205 mm
width	185 mm
depth	130 mm
net weight	4,9 kg

Environment
standards	IEC 60947-1 IEC 60947-3
product certifications	CCC KEMA-KEUR
IP degree of protection	IP40 IEC 60529
IK degree of protection	IK07 EN 50102
ambient air temperature for operation	-25…70 °C
ambient air temperature for storage	-50…85 °C

Offer Sustainability
Jätkusuutliku pakkumise olek	Green Premium toode
REACh-määrus	REACh-deklaratsioon
ELi RoHS direktiiv	Vastavus ELi RoHS deklaratsioon
Elavhõbedavaba	Jah
RoHS eranditeave	Jah
Hiina EoHS regulatsioon	Hiina RoHS deklaratsioon Toode ei kuulu Hiina RoHS sfääri. Ainedeklaratsioon teavitamiseks.
Keskkonnaalane avaldus	Toote keskkonnaprofiil
Ringlusprofiil	Kasutuselt kõrvaldamise teave
WEEE	Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.

Contractual warranty
Garantii	18 months
