switch-disconnector Interpact INSJ400 - 3 poles - 400 A

Product was successfully added to your shopping cart.

switch-disconnector Interpact INSJ400 - 3 poles - 400 A

Tootekood: 31136

Quick Overview

Saadavus: Tellimisel

193,16 € (ilma KM-ta)

Qty:

Details

Main
range	Compact
product name	INSJ400
switch-disconnector name	Interpact INSJ400
poles description	3P
network type	AC
network frequency	50/60 Hz
[Ie] rated operational current	400 A AC 50/60 Hz 600 V
[Uimp] rated impulse withstand voltage	8 kV
[Icm] rated short-circuit making capacity	100 kA protected by circuit breaker NSJ400 - 400A 480 V AC 50/60 Hz 150 kA protected by circuit breaker NSJ400 - 400A 240 V AC 50/60 Hz 20 kA protected by any protection device 600 V AC 50/60 Hz 25 kA protected by circuit breaker NSJ400 - 400A 600 V AC 50/60 Hz 50 kA with class T or RK fuses 400 A 600 V AC 50/60 Hz
[Ue] rated operational voltage	600 V AC 50/60 Hz
suitability for isolation	Yes
contact position indicator	Yes

Complementary
control type	Rotary handle
mounting mode	Fixed
mounting support	Plate
upside connection	Front
downside connection	Front Rear
mechanical durability	5000 cycles UL 489
electrical durability	1000 cycles full load
height	205 mm
width	185 mm
depth	130 mm
net weight	4,6 kg

Environment
standards	CSA C22.2 No 5.2 UL 489

Offer Sustainability
Jätkusuutliku pakkumise olek	Green Premium toode
REACh-määrus	REACh-deklaratsioon
ELi RoHS direktiiv	Vastavus ELi RoHS deklaratsioon
Elavhõbedavaba	Jah
RoHS eranditeave	Jah
Hiina EoHS regulatsioon	Hiina RoHS deklaratsioon Toode ei kuulu Hiina RoHS sfääri. Ainedeklaratsioon teavitamiseks.
Keskkonnaalane avaldus	Toote keskkonnaprofiil
Ringlusprofiil	Kasutuselt kõrvaldamise teave
WEEE	Tootest tuleb Euroopa Liidu turgudel vabaneda vastavuses erijäätmeseadustele ning see ei tohi sattuda olmeprügi sekka.

Contractual warranty
Garantii	18 months
