  • Thermal magnetic circuit breaker, TeSys GB2, 2P, 0.5 A, Icu 50 kA@415 V

Product was successfully added to your shopping cart.

Thermal magnetic circuit breaker, TeSys GB2, 2P, 0.5 A, Icu 50 kA@415 V

Ülevaaded: 0

Tootekood: GB2DB05

Quick Overview

Saadavus: Tellimisel

41,26 € (ilma KM-ta)

Details

Main
range
TeSys
product name
TeSys GB2
device short name
GB2
product or component type
Circuit breaker
device application
Control
poles description
2P
network type
AC/DC
utilisation category
Category A conforming to IEC 60947-2
DC-12 conforming to IEC 60947-5-1
DC-13 conforming to IEC 60947-5-1
network frequency
50/60 Hz conforming to IEC 60947-2
breaking capacity
50 kA Icu at 110 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
1.5 kA Icu at 24 V DC conforming to IEC 60947-2
1 kA Icu at 48 V DC conforming to IEC 60947-2
[Ics] rated service short-circuit breaking capacity
100 % at 110 V AC 50/60 Hz conforming to IEC 60947-2
25 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
25 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
trip unit technology
Thermal-magnetic
magnetic tripping current
6.6 A
Complementary
mounting mode
By clips
mounting support
Plate
Rail
mounting position
Horizontal
Vertical
control type
Toggle
[In] rated current
0.5 A
[Ue] rated operational voltage
415 V AC 50/60 Hz conforming to IEC 60947-2
48 V DC
[Uimp] rated impulse withstand voltage
IEC 60947-2 4 kV
power dissipation per pole
2 W
mechanical durability
8000 cycles
electrical durability
8000 cycles
connections - terminals
Connector 1 cable(s) 0.75…6 mm²solid without cable end
Connector 2 cable(s) 0.75…4 mm²solid without cable end
Connector 1 cable(s) 0.75…4 mm²flexible with cable end
Connector 2 cable(s) 0.75…2.5 mm²flexible with cable end
tightening torque
1.2 N.m on connector
mechanical robustness
Shocks: 22 Gn for 20 ms conforming to IEC 60068-2-27
Vibrations: 5 Gn, 5...110 Hz conforming to IEC 60068-2-6
quantity per set
Set of 3
9 mm pitches
4
height
74 mm
width
30 mm
depth
70 mm
net weight
0.115 kg
Environment
standards
EN/IEC 60947-1
EN/IEC 60947-2
protective treatment
TC
IP degree of protection
IP20 conforming to IEC 60529
ambient air temperature for operation
-20…60 °C
ambient air temperature for storage
-40…80 °C
fire resistance
960 °C conforming to IEC 60695-2-1
operating altitude
3000 m
Offer Sustainability
Sustainable offer status
Green Premium product
REACh free of SVHC
Yes
EU RoHS Directive
Toxic heavy metal free
Yes
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
China RoHS declaration
 Pro-active China RoHS declaration (out of China RoHS legal scope)
Environmental Disclosure
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty
Warranty
18 months
