transformer block for light block with integral LED - 440...460V

Ülevaaded: 0

Tootekood: ZBV8B

Quick Overview

Saadavus: Kesklaos, tarneaeg 2 – 4 tööpäeva

24,23 € (ilma KM-ta)

Details

Main
range of product
Harmony XB4
product or component type
Transformer block
product compatibility
Light block with integral LED 24 V AC
device short name
ZBV
sale per indivisible quantity
1
connections - terminals
Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN 60947-1
Screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to EN 60947-1
[Us] rated supply voltage
440...460 V AC at 60 Hz
Complementary
CAD overall width
30 mm
CAD overall height
33.6 mm
CAD overall depth
46.6 mm
net weight
0.09 kg
electrical shock protection class
Class I conforming to IEC 60536
supply voltage limits
441…459 V
surge withstand
1 kV conforming to IEC 61000-4-5
electrical composition code
M6
P2
device presentation
Basic element
Environment
ambient air temperature for storage
-40…70 °C
ambient air temperature for operation
-25…70 °C
IP degree of protection
IP20 conforming to IEC 60529
standards
EN/IEC 60947-5-4
EN/IEC 60947-5-5
JIS C 4520
CSA C22.2 No 14
EN/IEC 60947-5-1
UL 508
EN/IEC 60947-1
product certifications
GL
LROS (Lloyds register of shipping)
DNV
UL listed
RINA
CSA
BV
vibration resistance
2 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
shock resistance
15 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
resistance to electromagnetic fields
10 V/m conforming to IEC 61000-4-3
resistance to electrostatic discharge
6 kV in contact conforming to IEC 61000-4-2
8 kV in free air conforming to IEC 61000-4-2
electromagnetic emission
Class B conforming to IEC 55011
Offer Sustainability
Sustainable offer status
Green Premium product
REACh Regulation
REACh free of SVHC
Yes
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
Environmental Disclosure
Circularity Profile
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty
Warranty
18 months
