Details
Characteristics
| range of product | Multi 9 | |
|---|---|---|
| product or component type | Undervoltage release | |
| device short name | MN | |
| [Uc] control circuit voltage | 24 V AC 50/60 Hz24 V DC | |
| control type | Standard | |
| 9 mm pitches | 2 |
| range compatibility | Multi 9 C60Multi 9 C60H-DC | |
|---|---|---|
| local signalling | Action indicator | |
| mounting mode | Fixed | |
| mounting support | 35 mm symmetrical DIN rail | |
| height | 82.5 mm | |
| width | 18 mm | |
| depth | 68 mm | |
| connections - terminals | Pad terminal - 1 cable(s) 2.5 mm² - flexiblePad terminal - 1 cable(s) 2.5 mm² - rigidPad terminal - 2 cable(s) 1.5 mm² - flexiblePad terminal - 2 cable(s) 1.5 mm² - rigid | |
| wire stripping length | 9 mm | |
| tightening torque | 1 N.m |
| standards | EN/IEC 60947-5-1 | |
|---|---|---|
| product certifications | KEMAASEFALCIEASTA | |
| tropicalisation | 2 conforming to EN/IEC 60947-5-1 | |
| relative humidity | 95 % at 55 °C | |
| ambient air temperature for operation | -25…50 °C | |
| ambient air temperature for storage | -40…85 °C |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| REACh Regulation | ||
| EU RoHS Directive | Compliant EU RoHS Declaration | |
| Mercury free | Yes | |
| RoHS exemption information | ||
| China RoHS Regulation | China RoHS declaration Product out of China RoHS scope. Substance declaration for your information | |
| Environmental Disclosure | ||
| Circularity Profile | ||
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 18 months |
|---|
