Wall-Mounted Open Box 15U W600 D600 Fixed 19" Glazed Door R7035

Ülevaaded: 0

Tootekood: NSYOPB15U6F

Quick Overview

Saadavus: Tellimisel

648,17 € (ilma KM-ta)

Details

Main
range
Actassi
product name
Actassi OPB
product or component type
19" enclosure
device application
Cabling
applications
To protect network connectivity equipment
To mount 19" equipment
enclosure type
Open box
support equipment
2 x fixed 19" uprights recessed of 120 mm from the front (pitch 25 mm)
front face
Glazed door
door type
Front glazed door - with 1 point locking system (key: 333) - reversible opening at 180 °
accessibility for operation
Front
Side
Rear
removable parts
Front door removable toolless
Top blanking plate
Bottom blanking plate
Rear blanking plate
Side panels removable toolless
colour
Light grey (RAL 7035)
Complementary
device composition
3 x cable entries
1 x glazed door front
2 x panels side
2 x 19" uprights front
1 x open structure
load rating
50 kg static
3 kg by unit
back face
Cut-out
side face
Panel
number of cut-out
1 cut-outside
1 cut-outbottom
1 cut-outtop
installation mode
Wall mounted
material
Sheet steel: structure
Sheet steel: door
Sekurit glass: door
Galvanized steel: upright
surface finish
Epoxy-polyester powder
width
600 mm
height
780 mm
depth
600 mm
net weight
31 kg
number of rack unit
15U
Europe
Environment
IK degree of protection
IK08 conforming to IEC 62262
IP degree of protection
IP20 conforming to IEC 60529
standards
IEC 60297-3-100
EIA-310D
Offer Sustainability
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Environmental Disclosure
Contractual warranty
Warranty
18 months
