white light block for head Ø22 integral LED 24V pins

Product was successfully added to your shopping cart.

white light block for head Ø22 integral LED 24V pins

Tootekood: ZBVB17

Quick Overview

Saadavus: Tellimisel

13,59 € (ilma KM-ta)

Qty:

Details

Main
range of product	Harmony XB4 Harmony XB5
product or component type	Light block
device short name	ZBV
sale per indivisible quantity	5
connections - terminals	Pins for printed circuit board
signalling type	Steady
light source	Protected LED
bulb base	Integral LED
light block supply	Direct
light source colour	White
[Us] rated supply voltage	24 V AC/DC at 50/60 Hz

Complementary
net weight	0.004 kg
supply voltage limits	19.2…30 V DC 21.6…26.4 V AC
current consumption	18 mA
service life	100000 h at rated voltage and 25 °C
surge withstand	1 kV conforming to IEC 61000-4-5
mounting of block	Front mounting
electrical composition code	M1 M2 M3 M4 M5 M6 M10 MF1 P1 P2 PF1

Environment
protective treatment	TH
ambient air temperature for storage	-40…70 °C
ambient air temperature for operation	-40…70 °C
IP degree of protection	IP20 conforming to IEC 60529
standards	CSA C22.2 No 14 EN/IEC 60947-1 EN/IEC 60947-5-5 UL 508 EN/IEC 60947-5-4 JIS C8201-5-1 EN/IEC 60947-5-1 JIS C8201-1
resistance to fast transients	2 kV conforming to IEC 61000-4-4
resistance to electromagnetic fields	10 V/m conforming to IEC 61000-4-3
resistance to electrostatic discharge	6 kV on contact (on metal parts) conforming to IEC 61000-4-2 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2
electromagnetic emission	Class B conforming to IEC 55011

Offer Sustainability
Sustainable offer status	Green Premium product
REACh Regulation	REACh Declaration
REACh free of SVHC	Yes
EU RoHS Directive	Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration
Mercury free	Yes
RoHS exemption information	Yes
China RoHS Regulation	China RoHS declaration
Environmental Disclosure	Product Environmental Profile
Circularity Profile	End of Life Information
WEEE	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Contractual warranty
Warranty	18 months
