white light block with body/fixing collar with integral LED 48...120V

Ülevaaded: 0

Tootekood: ZB6EG1B

Quick Overview

Saadavus: Tellimisel

56,45 € (ilma KM-ta)

Details

Main
range of product
Harmony XB6
product or component type
Complete body for pilot lights
device short name
ZB6
sale per indivisible quantity
5
connections - terminals
Faston connectors, connection size: 2.8 x 0.5 mm
light source
LED
bulb base
Integral LED
light block supply
Direct
light source colour
White
[Us] rated supply voltage
48...120 V AC
Complementary
CAD overall height
14 mm
CAD overall depth
58 mm
terminals description ISO n°1
(X1-X2)PL
net weight
0.003 kg
operating position
Any position
[Ui] rated insulation voltage
250 V (pollution degree 3) conforming to EN/IEC 60947-1
[Uimp] rated impulse withstand voltage
EN 60947-1 4 kV
signalling type
Steady
supply voltage limits
40…132 V AC
surge withstand
1 kV in contact conforming to IEC 61000-4-5
2 kV in free air conforming to IEC 61000-4-5
Environment
protective treatment
TC
ambient air temperature for storage
-40…70 °C
ambient air temperature for operation
-25…70 °C
electrical shock protection class
Class II conforming to IEC 61140
standards
EN/IEC 60947-5-1
JIS C 852
CSA C22.2 No 14
JIS C 4520
EN/IEC 60947-1
UL 508
EN/IEC 60947-5-5
product certifications
CSA
GOST
UL
CCC
vibration resistance
+/- 3 mm (f= 2…500 Hz) conforming to IEC 60068-2-6
5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
shock resistance
30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
resistance to fast transients
2 kV conforming to IEC 61000-4-4
resistance to electromagnetic fields
10 V/m conforming to IEC 61000-4-3
resistance to electrostatic discharge
6 kV on contact (on metal parts) conforming to IEC 61000-2-6
8 kV in free air (in insulating parts) conforming to IEC 61000-2-6
electromagnetic emission
Class B conforming to IEC 55011
Offer Sustainability
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Mercury free
Yes
RoHS exemption information
China RoHS Regulation
Environmental Disclosure
Circularity Profile
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Contractual warranty
Warranty
18 months
